Double flanged Eccentric Butterfly Valves from China manufacturer

Double flanged Eccentric Butterfly Valves

Payment Terms:	T/T,L/C
Place of Origin:	Tianjin, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Packing: Plywood cases ctns

ISO9001 CE API609 AWWA,: Pressure:PN10/16

Production Capacity: 300,000

Delivery Date: usually within 1 months.

Double Langed Eccentric Butterfly Valve
1. Body: CI ,DI
2. Disc: DI, SS
3.Seat: EPDM,NBR
4.CE/ISO9001:2008

Tianjin Tanggu Tianshun Valve Co., Ltd. which is founded in 1993 is located in Tianjin Ocean High-new Technology and Development District . It is one of the long history valve manufacturers in Tianjin ,China , mainly produce kinds of valves ,including butterfly valve , check valve and gate valve ect.

Double Eccentric Butterfly Valve

Body : Ductile Iron , Casting Iron

Disc : Ductile Iron , Stainless Steel

Driving Style : actuator and pneumatic

Stem : Stainless Steel

Seat :EPDM ,NBR

Brand : TST-Tianshun

Size : DN50-DN1400 (2"-56")

Nominal Pressure : PN10 & PN16

Working Temperature :-15°c ~+150°c

Suitable Mediums: This kind of valve is suitable for adjusting and stop medium in the pipeline system of power station , water works, steel mile ,chemical industry , paper-making industry,

Water engineering and environmental constructions .

Design Standard : API609 BS5155 MSS-67-1995

Flange Standard : BS , DIN , ANSI ,JIS

ASE , ASD, BS10D,BS10E UNI

Test Standard : API598 ISO5208-1982

Feature:

1.Stucture length comply with international standard , facilitate international sales.

2. Body lining of rubber vulcanization ensure a stable driving torque.

3. .Ends of Body Rubber vulcanization adopt water line to fulfil various forms of the flange sealing requirements .

4. Apply for single standard valve installation .

5.Clients can choose lever , worm gear , pneumatic apparatus , electronic apparatus or combination driving operation according to working requirements .

6. Bolt fittings convenient in maintenancing and replacing .

7. Simple structure ,pins connect the stem and plate of valve , steadily positioning.

8.The customers can independently choose the plate (electroplating , nylon plating coating , epoxy coating )according to requirements.

9. The shaft seal can be use copper line and 0-rings combined sealing , lower part of the stem adopt bearing structure under positioning .
